36V 20Ah 25A BMS Fit Motor Power : 36V 200W 250W 350W 500W 700W (Max Matching 700W). 48V 20Ah 40A BMS Fit Motor Power : 48V 250W 350W 500W 750W 1000W 1500W (Max Matching 1500W). 52V 20Ah 40A BMS Fit Motor Power : 52V or 48V 250W 350W 500W 750W 1000W 1500W (Max Matching 1500W). QZF batteries are compatible with most of the motor kits on the market, such as BAFANG, Voilamart, CSC, Tongsheng, EBIKELING, etc. Built in SMART BMS with short circuit, over-current, over-heat, over-charge, over-discharge protection. This battery pack uses Panasonic 21700 cells, long runtime, deep discharge recover, extended service life and superb performance. It has a great cycle life: =80% Capacity After 1000 Cycles, no acid. (No spill or leak problems). Fully potted pack for the ultimate in battery protection. Each cell has its own fuse for ultimate in safety. Each pack have ran through a full charge and discharge test in produce, to make sure you are getting every amp hour you paid for. On/Off switch that controls battery discharge. The illuminated battery LED power indicator. Know the power level in real time. Use key lock to secure the battery to the bicycle frame to prevent theft. Original Panasonic TSL 21700 3.7V 4800mAh cells. 36V 20Ah/48V 20Ah/52V 20Ah Lithium Batteries SPECIFICATIONS. Configuration: 10S 4P (40 cells)/13S 4P(52 cells)/14S 4P(56 cells). Cycle Life: =80% Capacity After 800 Cycles. 365mm L 90mm W 110mm H(36V 20AH&48V 20AH) 365mm L 90mm W 110mm H (52V 20AH). Battery Net Weight : 3.8Kg/4.6Kg/5.0Kg. Maximum continuous charge current: 5A. Max Continuous Discharge Current: 25amp(BMS)/40amp/40amp. Peak Discharge Current: 75A/120A/120A. Charge Cut-off Voltage: 42V/54.6V/58.8V. Discharge Cut-off Voltage: 28V/36.4V/39.2V. 1pc Lithium Battery with Built-in BMS. 1pcs Battery holder with 30CM discharge cable soldered Andersom connector. 1pc 4A Charger with UK plug. 1pc Anderson to XT60 adapter line. Note:if u need any other connectors such as XT90, small bullet, big bullet, please make a note in your order, and we will provide it to u for free, thanks. This item is in the category “Sporting Goods\Cycling\Bike Components & Parts\Electric Bike Components”. The seller is “qzfbattery” and is located in this country: GB. This item can be shipped to United Kingdom.
- Voltage&Capacity: 48V 20AH 40S BMS(500W-1500W MOTOR)
- Country/Region of Manufacture: China
- Battery Type: Lithium Ion (Li-Ion
- Battery Capacity: 20 Ah
- Item Height: 110mm / 4.33″
- Item Width: 90mm / 3.54″
- Compatible Brand: BAFANG, Voilamart, CSC, Tongsheng, EBIKELING etc
- Material: 21700 Li-ion LiNiCoMnO2
- Number of Items: 112/104/80
- Color: Black
- Energy: 720Wh / 960Wh / 1040Wh
- Part Type: Battery
- Compatible Bike Type: Universal
- Item Length: 365mm / 14.37″
- For Bike Type: Universal
- Certification: CE,RoHS,MSDS
- Way of charge: CC/CV
- Cell Specification: Panasonic TSL 3.7V 4800mAh 21700 cells
- Application: E-bike , E-scooter , E-motorcycle
- Cycle Life: ≥80% Capacity After 1000 Cycles
- Item Weight: 8.4 lbs / 10.2 lbs / 11 lbs
- Brand: QZF
- Set Includes: UK Plug 4A charger
- Manufacturer Warranty: 1 year
- Voltage: 52V 48V 36V
- Colour: Black
